THERMAL TIRE PROTECTOR
Emergency vehicle protection against intense thermal loads in wildfire environments
Technical Specifications:
- Fabric: Flame-retardant, 4-layered, stitched and reinforced with Kevlar thread and tape
- Weave: Satin
- Composition: 95% fiberglass – 5% aluminum alloy 1050
- Fabric Weight: 450 g/m²
- Thickness: 0.4 mm
Thermal Protection Levels:
External protection against radiant and convective heat from flame exposure:
- Up to 600 kW flame intensity / Flame speed: up to 20 km/h
- Minimum safety distance: 1.5 m
Internal shelter protection:
- Flames up to 10.5 m wide / Power up to 80 MW
- No forced ventilation / Minimum distance: ≥ 2 m
Certifications:
Compliant with EN ISO 11612:2015 and UNE-EN 469/A1
Fabric tested under the following standards: EN ISO 15025, ISO 9151, EN ISO 6942, ISO 12127-1, ISO 17493, EN ISO 13934-1, EN ISO 13937-2, EN ISO 13935-2
Dimensions & Weight
| Vehicle Type | Tire Protector Size (Ø × H × W) | Carry Bag Size (L × H × W) | Weight |
|---|---|---|---|
| Light Vehicle | Ø800 × 800 × 230 mm | 750 × 250 × 600 mm | 2 kg |
| Heavy Vehicle | Ø1200 × 1200 × 400 mm | 750 × 250 × 600 mm | 2.5 kg |
